The WT10RX is a 10.1-inch rugged tablet powered by the advanced RK3588 Octa-core processor, combining four Cortex-A76 and four Cortex-A55 cores, with a main frequency of up to 2.4GHz. Operating on Android 12, it comes standard with 8GB of RAM and 256GB of ROM, with optional configurations of up to 16GB of RAM and 512GB of ROM to accommodate various indusries like construction, logistics, and precision agriculture.
High-Quality Display and Camera
The WT10RX features a 10.1-inch LCD touchscreen with 10-point multi-touch capability,providing a highly responsive and intuitive user experience.The display boasts a resolution of 1200×1920,ensuring sharp and vibrant visuals.Additionally,the tablet is equipped with a 5MP front camera and a 13MP rear camera,delivering excellent image quality for documentation,communication,and fieldwork.
Seamless Connectivity Anywhere
The WT10RX offers exceptional connectivity options to keep you connected in any environment. It supports WWAN and mobile communication, with integrated navigation systems including Beidou, GPS, and Glonass for precise location tracking. With 802.11a/b/g/n/ac/ax standards, Wi-Fi 6 compatibility, and dual-band support (2.4GHz and 5GHz), the tablet ensures fast and reliable wireless performance. Additionally, it functions as a wireless access point (Mobile AP) and features Bluetooth 5.0 for seamless device pairing and data transfer.
Multiple Connections for External Equipment
The WT10RX is designed to meet the diverse connectivity needs of industrial applications, offering robust communication options and peripheral support. Its extensive range of I/O ports includes USB 3.0, USB 2.0, SSD slot, Type-C, HDMI, RJ45, and RS232, making it compatible with a variety of external equipment. This flexibility allows you to connect peripherals such as sensors, printers, external storage, and industrial control systems, making the WT10RX an ideal solution for logistics, manufacturing, field service, and more.
Comprehensive Sensor Integration
The WT10RX is equipped with a wide range of sensors to enhance functionality and versatility. It includes a light sensor, geomagnetic sensor, G-sensor, gyroscope, acceleration sensor, and barometric sensor. These sensors provide advanced capabilities such as environmental awareness, precise navigation, and motion detection,making the tablet an excellent choice for demanding applications across various industries.
Specifications
| Model | WT10RX | |
| OS | Android 12 | |
|---|---|---|
| CPU | RK3588, 8 cores 2.4GHz, Cortex-A76*4+Cortex-A55*4 | |
| RAM/ROM | 8GB/256GB; 16GB/256GB | |
| LCD | 10.1 inch, 1200*1920; 450nits | |
| Touch | 10 point touch | |
| Camera | Front Camera: 5M, Rear Camera: 13M | |
| Power | Battery | 6000mAh; 7.6V |
| Charger | DC4.0, 12V*4A Type-C Fast Charging |
|
| WAN | Mobile Communication | LTE FDD: B1/B2/B3/B4/B5/B7/B8/E28/B66 LTE TDD: B40 WCDMA: B1/B2/B4/B5/B8 GSM: 850/900/1800/1900 |
| GPS | Beidou+GPS+glonass | |
| WIFI | 802.11a/b/g/n/ac/ax, Wireless AP / Mobile AP 2.4G, 5G support WiFi 6 |
|
| Bluetooth | 5.0 version | |
| NFC | ISO/IEC14443A, MIFARE, Felicia | |
| Speaker | 8Ω, 1.5Wx1 | |
| MIC | Sensitivity: ~32±2d, Output impedance: 2.2kΩx1 | |
| Sensor | Light Sensor | support |
| Geomagnetic Sensor | support | |
| G-Sensor | support | |
| Gyroscope | support | |
| Acceleration Sensor | support | |
| Barometric sensor | support | |
| SIZE | 275*178*18mm | |
| Weight | 1150 ± 50g | |
| Multi-media (Hardware decoding) | Picture Preview | BMP, JPG, GIF, PNG |
| Video Format | MPEG 1/2/4, H.263/H.264, RMVB, WMV, VC-1, MVC, AVS, MJPEG. (UP TO 1080P) | |
| Audio Format | MP3, WMA, WAV, OGG, FLAC, ALAC, APE, AAC, AC-3, DTS (need license) | |
| Language | multi language | |
| Interface | USB 3.0 | 1 |
| USB 2.0 | 1 | |
| SSD slot | 1 | |
| TYPE-C | 1 | |
| HDMI | 1 | |
| RJ45 | 1 | |
| RS232 | 1 | |
| DC Charging | 1 | |
| SIM | 1 | |
| TF | 1 | |
| 3.5mm Headphone | 1 | |
| Fingerprint | Optional | |
| UHF | Optional | |
| High-precision GPS | Optional | |
| Protection Level | 1. Waterproof IP65, designed with IP67 2. Drop test 1.2 meters |
|
| Certification Standards | 1. MIL-STD-810G 2. ISO |
|
| Temperature | 1. Storage temperature -25℃ to 80℃ 2. Operating temperature -20℃ to 55℃ |
|
